Flat edge polishing with liquid cerium
Straight-line edging machine for polishing the flat edge with liquid cerium. Great levels of finish for productions of particular value.
This edger is specifically designed and built to make a great contribution in terms of edge polishing quality, benefiting from the use of liquid cerium.
The construction features of the machine give it great reliability over time and guarantee very high quality productions, enhanced by an optimized level of finish thanks to the possibility of using liquid cerium.
The sturdy cast iron base, a distinctive feature of Bovone machines, avoids any possible torsion effect for absolute precision in grinding and polishing.
The design of the machine facilitates routine maintenance operations and wheel setup.
FULL AUTOMATIC Available
The ELB 10 straight-line edger can be supplied in the fully automatic version
Over the last two years Bovone has developed the new range of automatic glass edging machines presenting the new ELB Fully Automatic series at Vitrum.
Bovone’s ELB FA automatic edging machines for glass bring, in fact, a significant improvement in the degree of automation of grinding machines that translates into greater productivity and quality without compromise.
Bovone develops these two aspects of production by acting on three main points:
Automatic wheel wear compensation
No more hassle for the operator to manage manually the wheel position to compensate the wear during production. The machine’s spindles are positioned on a motorized track managed by the main software that raises automatically the position of the wheel.
Quick wheel setup
The machine wheel change results easier and faster than ever. The spindle lowers automatically leaving space for the operator to easily change the wheel, then rising up and positioning autonomously in the correct setup position.
Wheel change warning
Changing the wheels at the right time is essential to make the most of the tool and obtain a constant level of finish. A visual and audible alarm on the machine alerts the operator when the grinding wheel needs to be replaced.
Need more information?
Contact usTechnical features
| SPEED [m/min] | ARRIS WIDTH [mm] | MITER ANGLE | MINIMUN SIZE [mm] | THICKNESS [mm] | ELECTRICAL POWER 400V 50Hz | DIMENSIONS LxWxH [mm] | WEIGHT [Kg] |
|---|---|---|---|---|---|---|---|
| 0.35 - 5.4 | 5 | - | up to 6mm 40 x 40 up to 19mm 50 x 50 - 40 x 80 above 19mm 70 x 70 | 2 - 30 (OPT. 50) | 30kW 68A | 7950 1250 2900 | 4150 |
