Flat and inclined edge polished to perfection with liquid cerium
Variable angle straight-line edging machine for processing flat or inclined edges: excellent polishing thanks to the use of liquid cerium.
This machine is known all over the world for the extreme precision of flat or inclined edge processing: the solid cast iron base, an identifying feature of Bovone grinders, is the essential condition for guaranteeing this precision.
The stiffness of the machine together with the engineering allow to drastically reduce vibrations during processing: this generates tangible advantages in the precision and quality of the finish but also in the reduced wear of the machine.
The 10/45 is a real business card for Bovone: thanks to the numerous installations all over the world, this machine is tangible proof for the glass operators of the quality and performance that Bovone technologies are able to deliver.
The 10/45 edgers can be integrated into fully automated robotic systems.
FULL AUTOMATIC Available
The ELB 10/45 straight-line edger can be supplied in the fully automatic version
Over the last two years Bovone has developed the new range of automatic glass edging machines presenting the new ELB Fully Automatic series at Vitrum.
Bovone’s ELB FA automatic edging machines for glass bring, in fact, a significant improvement in the degree of automation of grinding machines that translates into greater productivity and quality without compromise.
Bovone develops these two aspects of production by acting on three main points:
Automatic wheel wear compensation
No more hassle for the operator to manage manually the wheel position to compensate the wear during production. The machine’s spindles are positioned on a motorized track managed by the main software that raises automatically the position of the wheel.
Quick wheel setup
The machine wheel change results easier and faster than ever. The spindle lowers automatically leaving space for the operator to easily change the wheel, then rising up and positioning autonomously in the correct setup position.
Wheel change warning
Changing the wheels at the right time is essential to make the most of the tool and obtain a constant level of finish. A visual and audible alarm on the machine alerts the operator when the grinding wheel needs to be replaced.
Need more information?
Contact usTechnical features
| SPEED [m/min] | ARRIS WIDTH [mm] | MITER ANGLE | MINIMUN SIZE [mm] | THICKNESS [mm] | ELECTRICAL POWER 400V 50Hz | DIMENSIONS LxWxH [mm] | WEIGHT [Kg] |
|---|---|---|---|---|---|---|---|
| 0,35 - 5,4 | 5 | 0°÷45° | fino a 12mm 65 x 65 - 85 x 85 - 105 x 105 da 12mm a 30mm 80x80 -100 x 100 - 150 x 150 - 90 x 200 | 3-30 (OPT. 60) | 31kW 72A | 8400 1250 2900 | 4800 |
